Fits
| Year | Make | Model | Engine |
| 2005-2012 | Dodge/Ram | 2500/3500 Crew Cab Long Box | 5.9L/6.7L Cummins |
Unlike most other tanks on the market, you don’t have to sacrifice your ground clearance when installing a larger tank as the S&B sits only 2.75″ below the OEM tank.
This S&B tank will reuse your factory-sending unit with zero modifications, just uninstall it from your factory tank and drop it into place on your S&B tank.
The innovative baffled design of this tank allows you to eliminate tank sloshing noise and keeps the fuel around the fuel pickup when driving on less-than-ideal terrain. This fuel tank uses the OEM locking ring. Ensuring a perfect seal and retaining the fuel pump onto the tank.
Part Number: 10-1018
Features
- Midship
- Compatible w/ Gooseneck and 5th wheel
- Compatible w/ OE Skid Plate
- Dimensions: 82.31″ X 17.68″ X 18.99″
- Drain: No
- 2.75″ Lower than OEM tank
- 25 extra gallons of fuel compared to the OEM tank
- Work with OEM sending unit
- 1/2″ Embedded fitting thread size
- Transfer pump ready
- Sump: No
- Straps Included
- Dry Weight: 48lbs
Installation
- Click Here
Notes
- This tank won’t fit trucks with aftermarket drivelines.
- NOT compatible with OEM skid plate
- The nozzle at high-flow fuel stations(truck stops) will not be able to fill automatically.
- OEM sending unit & float are reused because the S&B Tank is taller the gauge will stay on full for the first 8-10 gallons.
- Do you have an Auxiliary Fuel Tank? Read why using these with S&B tanks will void the Lifetime Warranty.
Warranty
Diesel Fuel Tanks
S&B replacement fuel tanks have a lifetime limited warranty for the original purchaser. If there is a problem with an S&B tank related to defect, materials or workmanship, S&B will replace it. All terms of the S&B Million Mile Limited Warranty also apply to S&B fuel tanks. Damage to an S&B fuel tank resulting from improper installation or use will not be covered by this warranty.
