Fits
| Year | Make | Model | Type |
| 2019-2024 | Dodge / Ram | 3500 w/ 6.7L Cummins & 4×4 | w/o Air-Ride |
BDS Suspension expands its listings for the late model 2019+ Cummins 3500 4WD diesel trucks with new 6″ 4-link conversion systems. Designed to improve the looks and performance of your new RAM, these new kits join existing radius arm variants to offer improved strength and handling on/off-road. This kit includes everything necessary to correctly lift them for improved offroad capability with room for larger tires while improving overall vehicle handling.
Part Number: BDS1690H
Features
- Forged drop pitman arm to correct steering angles
- HD bar drop bracket to re-center the front axle
- Sway Bar drop brackets to reposition the OE sway bar for optimal performance
- NX2 or Fox shocks
- HD replacement transmission cross-member
- Transfer case indexing ring to maintain use of the 4wd
- Allows for clearance of up to 37″ tires
- 5″ Rear blocks
- 4-link 1/4″ steel brackets, high strength upper & lower control arms
Tire & Wheel Combinations:
- 37×12.50 w/ 20×9 and 4.5-5.625″
- 37×12.50 w/ 20×9 and 5.625″
Notes
- T-case indexing ring available for 6-bolt and 8-bolt equipped models, check the vehicle before ordering
- Will not fit Cab and Chassis models
- Will NOT fit rear air-ride equipped models
- Diesel models only
- Will NOT Fit Mega Cab Aisin Transmissions (8-bolt)
- Does not fit Dually Models with 8-bolt Transmissions (Aisin)
- Does not work with manual shift transfer cases
Installation
- Click Here For Installation Instructions
- Difficulty: 3 (where 1 = easiest and 5 = complicated)
