Custom HP Tuner Files from MotorOps for 2017–2019 Duramax Trucks

Description

Description

Fits

Year	Make	Model
2017-2019	Chevy	Silverado
2017-2019	GMC	Sierra

Step up the driving experience on your 2017-2019 Chevy Silverado or GMC Sierra with a Motor Ops custom single tunes. Chose from: Optimized Stock Tune, Heavy or Light Tow Tunes, Sport economy or Race / Maximal Effort.

Hardware and licensing not included (See Notes).
Single Tunes Only

Tuning

Single Tune Power Levels options are as follows

Optimized Stock Tune

• Refined factory settings
• Smoother running engine & power delivery
• Reduced exhaust temperatures
• Leaves factory rev limit in place

Heavy Tow Tune

• For those towing from 8,000 lbs up to GVWR (Gross Vehicle Weight Rating)
• +90 RWHP, +120 ft-lbs torque over factory
• Wider torque curve assists heavy loads
• Perfect balance of sport driving & functionality
• Exhaust temperatures drop up to 100F under full load

Light Tow Tune

• For those towing any load up to 8,000 lbs
• +110 RWHP, +200 ft-lbs torque over factory
• Designed for weekend tower, boats, small tractors, etc
• Perfect balance of sport driving & functionality
• Unhook and enjoy a sportier drive

Sport Economy Tune

• Fun unloaded daily driving
• For driving around town, highways
• Impress your friends
• Put a smile on your face
• +140 RWHP, +300 ft-lbs torque over factory
• Puts your vehicle near the 550 RWHP mark

Race / Max Effort Tune

• Maxes out the factory Turbo
• +210 RWHP, +500 ft-lbs torque over factory
• Puts your vehicle near the 600 RWHP 1360 ft-lbs mark
• Up to 620 RWHP / 1380 ft. lbs with WC Fab turbo mouthpiece
• Strongly recommend transmission tune to avoid premature wear

Transmission Tuning

Transmission Tuning (Optional Add On)

• Increased transmission line pressure for holding more HP and torque
• Revised shift schedule to improve drive-ability
• Keeps the truck on top of the turbo
• Improved shift timing
• Re-designed torque converter lock-up strategy
• Allows power transfer from the engine to the wheels more directly
• Unlocked T87A TCM
• 4 required HP Tuners Universal Credits

Notes

Required for Tuning the L5P ECM (2017-2018)

• HP Tuners MPVI3 – this is used for programming the ECM and TCM if you decide to do so.
• HP Tuners E41 Upgrade Cable – this cable is used to unlock the factory ECM which then allows for a modified calibration to be loaded into the vehicle.
• HP Tuners Universal Credits – 4 Universal Credits are required for programming the ECM and 4 Universal Credits are required for programming the TCM (TCM is optional and can be done at a later date).
• Unlocked T87A TCM – This is required if you are doing a transmission tune. The factory TCM must be unlocked prior to tuning. This Unlocked TCM will actually replace your factory TCM.
• BOD Engineering 17-19 Can Bus Plugs

Required for Tuning the L5P ECM (2017-2019)

• HP Tuners MPVI3 – this is used for programming the ECM and TCM if you decide to do so.
• HP Tuners Universal Credits – 4 Universal Credits are required for programming the ECM and 4 Universal Credits are required for programming the TCM (TCM is optional and can be done at a later date).
• Unlocked T87A TCM – This is required if you are doing a transmission tune. The factory TCM must be unlocked prior to tuning. This Unlocked TCM will actually replace your factory TCM.
• BOD Engineering 17-19 Can Bus Plugs
