Description
Description
Fits
| Year | Make | Model | Engine |
| 1995-1996 | Ford | F-250/F-350 2WD | 7.3L Powerstroke |
| 1997 | Ford | F250 HD 2WD | 7.3L Powerstroke |
BD’s stock E4OD is built to handle stock engine output, featuring an HD transmission pan & auxiliary transmission filter kit for added protection!
Part Number: 1064422F
Features
- Machined center support
- Machined intermediate piston
- Machined low/reverse pressure plate
- Machined rear ring gear hub
- Added lube circuits to OD planet
- Added lube and support to output and intermediate shafts
- Replaced all aluminum planetaries with steel
- Drilled and tapped direct and intermediate feeds to prevent leaks at case
- Re-programmed accumulator body
- Full shift kit with line mod valve to increase pressures
- Accumulator body enhanced oil flow
- Increased cooler pressure
- Increased pressure to converter
- Creates positive clutch application
- Created lube circuit for towing in overdrive
- 1990-2003 include auxiliary frame mounted full flow filter kit
- Pan adds 6qt extra oil capacity
- Fully rollerized geartrain
- Tighter clutch packs that provide a quicker shift
- 30%-40% more clutch material with additional steels
- Improved internal lubrication by adding high power boost valves
- Reworked front pump
- Improved bearing designs
- Upgrade supports
- Upgraded sprags
- Sure-loc snap rings
- Solenoids hard wiring providing high temperature resistance
- Increase the durability of your drivetrain
- Revised oil circuits
- Handles up to 300% more power and torque than the stock transmission
- Extra clutches and stronger internals
- BD rigid aluminum heavy duty transmission pan
- Pan reduces case flex
- Pan reduces internal oil leakage
- Pan heat-dissipating fins keep temperature down
- Pan magnetic drain plug
- Clutch Count: COAST CLUTCH 2
- Clutch Count: FORWARD 5
- Clutch Count: DIRECT 5
- Clutch Count: LOW REVERSE 7
- Clutch Count: INTERMEDIATE 4
- Clutch Count: OVERDRIVE 4
- Each transmission is dyno tested
Installation
- 5-Hours
- Auxiliary Filter Kit – Click Here
- Install – Click Here
Notes
- Add “PTO” to part number for PTO provision (i.e. 1064444FPTO or 1064444FPTOLR)
Warranty
Parts Only – No race abuse covered.
- 36-Months
- 150,000
- BD torque converter must be installed at the time of installation of the transmission – use of a 3rd party or OE converter will invalidate the transmission warranty.
